Description Overview R12/110/8 Horse Fence has pre-stripped ends for ease of joining. It features solid vertical wires, close vertical wire spacings to help prevent damage to hooves, and the unobtrusive high pressure bonded Torus knot which does not have any sharp edges. Tornado Torus Horse Fence is manufactured with high tensile wire which strains tighter than mild steel and so requires fewer intermediate posts, making it quicker to erect. It does not stretch with weathering so does not need to be retightened annually. Installation Guidelines A straining post is required at every major change in direction or any termination and should be supported by a strut or box assembly. Netting should be tied off on the straining posts by hand or with suitable joiners. When tensioning the fence the ‘crimp’ in the net should be reduced by approx: 50%. Avoid driving staples tight against the wire as this will damage the galvanised coating. Recommended use with Centaur, rail or lightning to add additional height and visability. Specification No. of Line Wires 12 Overall Height (cm) 110 Distance between stay wires (cm) 8 Top & bottom line wire specification 2.5mm dia – 1235-1390 N/mm2 Intermediate line wire specification 2.5mm dia – 1235-1390 N/mm2 Vertical stay wire specification 2.5mm dia – 695-850 N/mm2 Average Weight per 50 Metre Roll (kg) 59.45 Material Composition Heavily galvanised steel wire
